Parameters

• Fingerprint Capacity

  20,000

• Face Capacity

  12,000

• Palm Capacity

  6,000

• Card Capacity

  20,000

• Transaction Capacity

  200,000

• Communication

  TCP / IP / USB Host / Wiegand Output

• Access Control Interface

  Lock Relay Output / Alarm Output / Exit Button / Door Sensor / External Bell

• Hardware

  1.4GHz Quad Core CPU / Memory 1G RAM / 1G Flash / SilkID Fingerprint Sensor / 4.3 Inches Touch Screen / Hi-Fi Voice & Indicator / Tamper Switch Alarm

• Standard Function

  ID Card / Work Code / WDMS / DST / SMS / Bell Schedule / Attendance Status Auto-Switch / Record Query / Photo ID / Custom Wallpaper & Screen Saver

• Special Function

  Multiple Biometric Verification Modes
  Alive Face / Palm Detection
  Duplicate Face / Palm Detection

• Optional Function

  HID Proxy / IC Card Reader
  Wi-Fi / 3G
  External Printer
  Battery (2,000 mAh)
  POE (Standard IEEE 802.3at)

• Compatibility

  BioTime8.0 / ZKBioSecurity (T&A) / WDMS

• Algorithms

  ZKFace v12.0 & ZKFinger v10.0 & ZKPalm V12.0

• Current Draw

  < 500 mA

• Dimension

  199.2 × 171.8 × 96.9 mm

• Face

  FAR≤0.001%; FRR≤1%

• Fingerprint

  FAR≤0.0001%; FRR≤0.01%

• Operating Temperature

  0 °C ~ 45 °C

• Operating Voltage

  12V DC

• Palm

  FAR≤0.01%; FRR≤1%
