Model
SensePalm T1
SensePalm T2
-
Display
2.4" TFT Color LCD Screen (320*240)
-
Camera
Monocular Palm Authtication Camera @ 1MP
-
Operation System
Linux
-
Hardware
SensePalm T1: CPU: Dual-Core @ 1GHz; RAM: 512MB; ROM: 512MB; Speaker: 8ohm @1W; Supplement Light: Near-Infrared Light*4; Physical Keypad: 16 Keys; Color: Black; Fingerprint Sensor: ZK Optical Sensor
SensePalm T2: CPU: Dual-Core @ 1GHz; RAM: 512MB; ROM: 512MB; Speaker: 8ohm @1W; Supplement Light: Near-Infrared Light*4; Physical Keypad: 16 Keys; Color: Black; Fingerprint Sensor: ZK Optical Sensor
-
Authentication Method
Palm / Fingerprint / Card (Optional) / Password (Physical Keypad)
-
Fingerprint Capacity
1,500 (1:N) (Standard)
-
Card Capacity
3,000 (1:N) (Standard)
-
User Capacity
3,000 (1:N) (Standard)
-
Transaction Capacity
150,000
-
Max. User Password Length
8 digits
-
Biometric Authentication Speed
Authentication Speed
Less than 0.5 sec (Fingerprint), less than 0.35 sec (Palm Authentication)
-
Touchless Biometric Recognition Distance
8cm to 15cm (Palm)
-
False Acceptance Rate (FAR) %
FAR=0.001% (Palm), FAR ≤ 0.0001% (Fingerprint)
-
False Rejection Rate (FRR) %
FRR=0.17% (Palm), FRR≤0.01% (Fingerprint)
-
Biometric Algorithm
ZKPalmVein V21.3, ZKFingerprint V13.0 (Standard) / V10.0 (Optional)
-
Card Type
ID Card: 125 kHz (Optional), IC Card: 13.56 MHz (Optional)
-
Communication
Wi-Fi (IEEE 802.11b/g/n/ax) @ 2.4GHz; Wi-Fi 6 Enabled
USB: Type A 2.0 *1 (USB Drive Only)
-
Standard Functions
ADMS, DST, Workcode, Up to 14-digit User ID, Record Query, Schedule Bell, Automatic Status Switch / Self-Service Report (Effective only under T&A rules), Multiple Authentication Methods, HTTPS for cloud/Web access; SSH for backend maintenance; T9 Keyboard (Input), Online Firmware Upgrade
-
Optional Functions
ID Card, IC Card, Backup Battery
-
Power Supply
DC 5V 2A
-
Operating Temperature
-5°C to 45°C
-
Operating Humidity
20% to 80% RH (Non-condensing)
-
Backup Battery (Optional)
2,000mAh (Lithium Battery)
Operating Hours: 2 Hours
Max.Standby Hours: 3.5 Hours
Estimated Charging Time: 5 Hours
-
Dimensions
117.5 mm*116.6 mm*31.0 mm (L*W*H)
-
Gross Weight
0.45 Kg
-
Net Weight
0.24 Kg
-
Supported Software
Cloud-based Software: ZKBio Zlink by default (Supports Web Portal & Mobile App)
On-Premise Software: ZKBio Time (TA PUSH)
-
Installation
Wall mount (Compatible with Asian Gang-Box/ Single Gang-Box)
Desk mount (Compatible with Rots-4 desktop stand)
-
Certifications
ISO 9001, ISO14001, CE, FCC, Equivalent to RoHS
-
Order ID
SensePalm T1: TA01-PV01H-21
SensePalm T2: TA01-PV010H-21
